Copper Clad 310s Stainless Steel Plate 24 Gauge 204 314 2b Surface 5 X 10 48 X 96 8' X 4'

Basic Information
Place of Origin: Jiangsu, China
Brand Name: Changjian
Certification: ISO9001, CE
Minimum Order Quantity: 1 ton
Delivery Time: 7~10working days
Payment Terms: L/C, T/T
Supply Ability: 5000 Ton/Tons per Month
Detail Information
Product Name: Stainless Steel Sheet Type: Cold Rolled,Hot Rolled
Surface: No.1,2D,2B,BA,No.4,8k,Tempered Thickness: 0.4mm~6mm
Highlight:

310s stainless steel plate 24 gauge

,

copper clad 310s stainless steel plate

,

314 stainless steel sheet 2b surface


Product Description

Grade 204 Cu Stainless Steel Sheet

200 SERIES STAINLESS STEEL



200 Series stainless steels are not new – In fact they have been around for many years. To date they have traditionally not proved very popular outside the USA. However, since they have a much lower Nickel content than 300 Series Austentics, the very high Nickel price over recent years has led to significantly more interest. Equally, stainless steel producers have an ongoing programme of development designed to enhance existing grades and produce new grades. These new grades are sometimes developed for specific end uses and sometimes to improve upon an existing grade.



DESIGNATIONS


AISI 201 stainless steel corresponds to the following specifications:
UNS20100 / EN1.4372 / JIS SUS 201
AISI 201L stainless steel corresponds to the following specifications:
UNS20103 / EN1.4371
AISI 202 stainless steel corresponds to the following specifications:
UNS20200 / EN1.4373
AISI 204C stainless steel corresponds to the following specifications:
UNS20400 / EN1.4597

CHEMICAL COMPOSITION

Element C Mn Cr Ni Cu

AISI 201/UNS S20100

0.15%Max 5.50~7.50% 16.0~18.0% 3.50~5.50% -
AISI 202/UNS S20200 0.15%Max 7.50~10.0% 17.0~19.0% 4.00~6.00% -
UNS 20430/204 Cu 0.15%Max 6.50~9.0% 15.5~17.5% 1.5~3.5% 2.0~4.0%
UNS 20500 0.12~0.25% 14.0~15.5% 16.5~18.0%

1.0~1.75%

-



MECHANICAL PROPERTIES

Grade

Tensile Strength

(MPa)

Min

Yield Strength

(MPa)

Min

Elongation

(%in 50mm)

Min

200 series



655



310 40



200 Series COMMON APPLICATIONS



  • Furniture
  • Bins
  • Cookware & Serving Bowls
  • Window Channel Spacers
  • Safety Shoes (mid-sole protector)
  • Deep drawn kitchen equipment – e.g. Cookware & Sinks
  • Hose Clamps
  • Trailer Frames
  • Industrial Strapping
  • Railway Rolling Stock

There is also grade 201LN for welded constructions, structural uses and low temperature applications - Examples include sides & roofs of trains, liquified gas storage vessels, structural members/chassis of railway rolling stock, trucks & trailers, coal handling equipment
