| Place of Origin: | Jiangsu,China |
|---|---|
| Brand Name: | Changjian |
| Certification: | ISO 9001 ,CE |
| Minimum Order Quantity: | 5 TON |
| Delivery Time: | 7~10 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000 Ton/Tons per Month |
| Product Name: | Carbon Steel Pipe | Standard: | ASTM,ASME,API |
|---|---|---|---|
| Type: | Welded Pipe(ERW) | Pipe End: | Plain End,Beveled End,Treaded |
| Highlight: | carbon steel gas pipe a106,carbon steel gas pipe gr c,Natural Gas a106 steel pipe |
||
A106 pipe is American standard material, including A, B, C three grades, the ingredients of A106 A is carbon and silicon, the tensile strength grade is 330 MPa. The ingredients of A106 B is carbon,manganese and silicon, the tensile strength grade is 415 MPa. The ingredients of A106 C is carbon, manganese and silicon components, the tensile strength grade is 485 MPa.
MECHANICAL PROPERTIES
| Seamless&Welded | Tensile Strength | Yield Strength |
|
A106 Grade A |
330MPa |
205MPa |
| A106 Grade B | 415MPa | 240MPa |
| A106 Grade C | 485MPa | 275MPa |
CHEMICAL COMPOSITION
| Element | Carbon,C | Manganese,Mn | Ohosphorous,P | Sulfur,S |
| A106 Grade A | 0.25% | 0.27~0.29% | 0.035% | 0.035% |
| A106 Grade B | 0.30% | 0.29~1.06% | 0.035% | 0.035% |
| A106 Grade C | 0.35% | 0.29~1.06% | 0.035% | 0.035% |
PLEASE NOTE
For each reduction of 0.01% for maximum carbon element, an increase of 0.06% manganese above the specified value shall be permitted, and up to maximum of 1.35%.
Elements Cr, Cu, Mo, Ni, V combined shall not exceed 1%.
