ASTM A312 TP316L 3 Inch Schedule 10S Seamless Stainless Steel Pipe For Petrochemical Applications
Product Details
Precision Stainless Steel Tube Pipe
,Seamless Stainless Steel Tube Pipe
,Seamless Round Stainless Steel Tube
ASTM A312 TP316L 3 Inch Schedule 10S Stainless Steel Seamless Pipe is a corrosion-resistant austenitic stainless steel pipe designed for demanding petrochemical, chemical processing, oil and gas, and industrial piping applications. Manufactured to ASTM A312/A312M requirements, TP316L offers excellent resistance to chloride-containing environments, chemical media, and general corrosion.
| Parameter | Specification |
|---|---|
| Product Name | 3 Inch Schedule 10S Seamless Stainless Steel Pipe |
| Material Grade | ASTM A312 TP316L |
| Standard | ASTM A312 / A312M |
| Pipe Size | NPS 3 Inch |
| Nominal Diameter | DN80 |
| Schedule | 10S |
| Outside Diameter (OD) | 3.500 in. / 88.90 mm |
| Wall Thickness | 0.120 in. / 3.05 mm |
| Inside Diameter (Approx.) | 3.26 in. / 82.80 mm |
| Manufacturing Process | Seamless |
| Pipe Type | Austenitic Stainless Steel Pipe |
| Surface | Pickled / Annealed, or as specified |
| End Type | Plain End / Beveled End |
| Length | 5.8 m / 6 m / 11.8 m / 12 m, or customized |
| Heat Treatment | Solution Annealed |
| Testing | Hydrostatic or Nondestructive Electric Test as specified by ASTM A312 |
| Application | Petrochemical Processing, Chemical Processing, Process Piping, Oil & Gas |
The Schedule 10S wall thickness provides a lightweight piping solution for applications where corrosion resistance, clean internal surfaces, and reliable mechanical performance are more important than heavy-wall pressure containment.
As a seamless stainless steel pipe, TP316L Schedule 10S is manufactured without a longitudinal weld seam, making it suitable for piping systems requiring consistent structural integrity and resistance to localized corrosion.
Our 3 inch 316L Schedule 10S pipe is manufactured to ASTM A312 requirements and is available with standard NPS dimensions for process, chemical and petrochemical piping. The following table provides key 3 inch stainless steel pipe dimensions, including nominal size, outside diameter, wall thickness and approximate inside diameter.
| Nominal Pipe Size (NPS) | DN | Schedule | Outside Diameter (OD) | Wall Thickness | Approx. Inside Diameter | Approx. Weight |
|---|---|---|---|---|---|---|
| 1/2" | DN15 | 10S | 21.34 mm | 2.11 mm | 17.12 mm | 1.00 kg/m |
| 3/4" | DN20 | 10S | 26.67 mm | 2.11 mm | 22.45 mm | 1.28 kg/m |
| 1" | DN25 | 10S | 33.40 mm | 2.77 mm | 27.86 mm | 2.09 kg/m |
| 1-1/4" | DN32 | 10S | 42.16 mm | 2.77 mm | 36.62 mm | 2.69 kg/m |
| 1-1/2" | DN40 | 10S | 48.26 mm | 2.77 mm | 42.72 mm | 3.11 kg/m |
| 2" | DN50 | 10S | 60.33 mm | 2.77 mm | 54.79 mm | 3.93 kg/m |
| 2-1/2" | DN65 | 10S | 73.03 mm | 3.05 mm | 66.93 mm | 5.26 kg/m |
| 3" | DN80 | 10S | 88.90 mm | 3.05 mm | 82.80 mm | 6.45 kg/m |
| 4" | DN100 | 10S | 114.30 mm | 3.05 mm | 108.20 mm | 8.34 kg/m |
| 5" | DN125 | 10S | 141.30 mm | 3.40 mm | 134.50 mm | 11.62 kg/m |
| 6" | DN150 | 10S | 168.28 mm | 3.40 mm | 161.48 mm | 13.92 kg/m |
| 8" | DN200 | 10S | 219.08 mm | 3.76 mm | 211.56 mm | 19.95 kg/m |
| 10" | DN250 | 10S | 273.05 mm | 4.19 mm | 264.67 mm | 27.74 kg/m |
| 12" | DN300 | 10S | 323.85 mm | 4.57 mm | 314.71 mm | 35.98 kg/m |
The ASTM A312 TP316L pipe dimensions are specified according to the applicable stainless steel pipe dimensional requirements. For the featured 3-inch size, the pipe has an outside diameter of 88.90 mm and a nominal wall thickness of 3.05 mm under Schedule 10S. The approximate internal diameter is 82.80 mm.
Schedule 10S Stainless Steel Pipe Dimensions
Schedule 10S stainless steel pipe dimensions are commonly used for stainless steel process piping where a lighter wall configuration is suitable for the design conditions. The “10S” designation identifies the stainless steel pipe schedule, while TP316L identifies the material grade.
For the featured product:
NPS 3 × Schedule 10S = 88.90 mm OD × 3.05 mm wall thickness
Actual dimensional tolerances should be verified against the applicable ASTM A312 and ASME dimensional requirements.
3 Inch 316L Schedule 10S Pipe for Petrochemical ApplicationsThe 3 inch 316L Schedule 10S pipe is suitable for a range of petrochemical and chemical processing systems where corrosion resistance, dimensional consistency and reliable service performance are required. The seamless construction makes this pipe a suitable option for various process piping applications.
Typical applications include:
- Petrochemical processing
- Chemical processing
- Oil and gas facilities
- Refinery process piping
- Heat exchanger systems
- Fluid transfer lines
- Industrial process equipment
Typical chemical composition requirements for ASTM A312 TP316L / UNS S31603 include:
| Element | Typical Requirement, wt.% |
|---|---|
| Carbon (C) | ≤ 0.030 |
| Manganese (Mn) | ≤ 2.00 |
| Silicon (Si) | ≤ 1.00 |
| Phosphorus (P) | ≤ 0.045 |
| Sulfur (S) | ≤ 0.030 |
| Chromium (Cr) | 16.0–18.0 |
| Nickel (Ni) | 10.0–14.0 |
| Molybdenum (Mo) | 2.0–3.0 |
| Iron (Fe) | Balance |
Typical minimum mechanical requirements for TP316L stainless steel pipe include:
| Property | ASTM A312 TP316L |
|---|---|
| Tensile Strength | ≥ 485 MPa |
| Yield Strength | ≥ 170 MPa |
| Elongation | ≥ 35% |
| Hardness | As specified by ASTM A312 |
Schedule 10S is a commonly specified stainless steel pipe wall designation under ASME B36.19M.
Typical nominal pipe sizes include:
| Nominal Size | NPS | Outside Diameter |
|---|---|---|
| 1/2" | DN15 | 21.3 mm |
| 3/4" | DN20 | 26.7 mm |
| 1" | DN25 | 33.4 mm |
| 1-1/4" | DN32 | 42.2 mm |
| 1-1/2" | DN40 | 48.3 mm |
| 2" | DN50 | 60.3 mm |
| 2-1/2" | DN65 | 73.0 mm |
| 3" | DN80 | 88.9 mm |
| 4" | DN100 | 114.3 mm |
| 6" | DN150 | 168.3 mm |
| 8" | DN200 | 219.1 mm |
| 10" | DN250 | 273.1 mm |
| 12" | DN300 | 323.9 mm |
Petrochemical facilities often handle hydrocarbons, process chemicals, corrosive fluids and elevated-temperature services. Material selection therefore needs to consider corrosion resistance, pressure, temperature, fluid composition and applicable piping codes.
316L stainless steel seamless pipe is frequently selected when improved corrosion resistance over 304 stainless steel is required.
Typical advantages include:
- Better chloride pitting resistance than 304 stainless steel
- Good resistance to many chemical environments
- Excellent weldability
- Good ductility and toughness
- Suitable for demanding industrial piping
- Low-carbon grade for welded fabrication
- Seamless construction for process piping applications
ASTM A312 TP316L Schedule 10S Stainless Steel Seamless Pipe can be used in a range of petrochemical and process-industrial applications, subject to engineering design and service conditions.
- Petrochemical process piping
- Chemical processing plants
- Oil and gas processing systems
- Refinery piping
- Hydrocarbon processing equipment
- Chemical transfer lines
- Process fluid piping
- Heat exchanger piping
- Condensate lines
- Utility piping
- Instrumentation and auxiliary piping
- Corrosive fluid transportation
- Offshore and marine process systems
| Property | TP316L | TP304 |
|---|---|---|
| Chromium | 16–18% | 18–20% |
| Nickel | 10–14% | 8–11% |
| Molybdenum | 2–3% | Not intentionally added |
| Chloride Resistance | Higher | Moderate |
| Pitting Resistance | Better | Lower |
| Weldability | Excellent | Excellent |
| Chemical Processing | Excellent | Good |
| Petrochemical Applications | Excellent | Good |
| Relative Cost | Higher | Lower |
As a stainless steel and specialty metal supplier, JUDE STEEL can provide TP316L seamless stainless steel pipes for industrial and engineering applications.
- ASTM A312 TP316L material available
- Schedule 10S and other schedules available
- Seamless and welded stainless steel pipe options
- Multiple OD and wall thickness options
- Custom lengths available
- Material certificates available
- Chemical and mechanical test reports available
- Support for project-based purchasing
- Export packing for international orders
- Technical documentation available upon request
A: ASTM A312 TP316L is a low-carbon austenitic stainless steel pipe grade specified for seamless and welded pipe used in corrosive and high-temperature service. TP316L corresponds to UNS S31603.
A: Schedule 10S is a stainless steel pipe wall designation generally associated with ASME B36.19M. The actual wall thickness depends on the nominal pipe size.
A: Yes. When specified as a seamless pipe, it is manufactured without a longitudinal weld seam. ASTM A312 also covers welded stainless steel pipe, so the manufacturing type should be clearly stated on the purchase order.
A: In many corrosive environments, 316L provides better resistance to pitting and crevice corrosion because it contains molybdenum. However, the appropriate grade should always be selected based on the actual process medium, temperature, chloride concentration and design conditions.
A: Yes. TP316L has good weldability and is commonly welded using TIG, MIG and other suitable stainless steel welding processes. Welding procedures should follow the applicable project specifications and welding codes.
A: Yes. EN 10204 3.1 Mill Test Certificates can be provided when required, including chemical composition and mechanical test results for the supplied material.
A: We can supply a range of nominal pipe sizes according to ASME B36.19M Schedule 10S, with OD, wall thickness and length options depending on availability and project requirements.
A: Schedule 10S is a stainless steel pipe designation used with ASME B36.19M, while Schedule 10 is generally associated with carbon and alloy steel dimensions under ASME B36.10M. For stainless steel piping, the applicable dimensional standard should be confirmed.
-
