| Place of Origin: | Jiangsu, China |
|---|---|
| Brand Name: | Changjian |
| Certification: | ISO9001, CE |
| Minimum Order Quantity: | 1 ton |
| Delivery Time: | 7~10working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000 Ton/Tons per Month |
| Product Name: | Stainless Steel Sheet | Type: | Cold Rolled,Hot Rolled |
|---|---|---|---|
| Surface: | No.1,2D,2B,BA,No.4,8k,Tempered | Thickness: | 0.4mm~6mm |
| Highlight: | 443 mirror stainless steel plate,stainless steel sheets 4x8 ss304,48x96 mirror stainless steel plate |
||
Grade 443 Stainless Steel Sheet
400 SERIES STAINLESS STEEL
Stainless steel 443, which is a kind of ferritic stainless steel, is now generally used to replace 304. Its rust resistance and processing performance are comparable to those of 304. It is currently widely promoted in the fields of electrical appliances, utensils, kitchen equipment, elevators, and oven making.
CHEMICAL COMPOSITION
| Element | C | Mn | Cr | Ni | P | S | Si |
| 409 | 0.03% | 1.00% | 10.5~11.7% | 0.50% | 0.04% | 0.02% | 1.00% |
| 410 | 0.08~0.15% | 1.00% | 11.5~13.5% | 0.75% | 0.04% | 0.03% | 1.00% |
| 420 | 0.15% | 1.00% | 12.0~14.0% | - | 0.04% | 0.03% | 1.00% |
| 430 | 0.12% | 1.00% | 16.0~18.0% | 0.75% | 0.04% | 0.03% | 1.00% |
| 443 | 0.02% | 1.00% | 18.0~23.0% | 0.50% | 0.04% | 0.03% | 1.00% |
MECHANICAL PROPERTIES
| Grade |
Tensile Strength (MPa) Min |
Yield Strength 0.2% proof (MPa) Min |
Elongation (%in 50mm) Min |
Brinell(HBW) |
| 443 |
517
|
615 | 32 | 434 |
443 COMMON APPLICATIONS
The typical applications of grade 443 stainless steels are listed below:
