Product Name: | Stainless Steel Sheet | Type: | Cold Rolled,Hot Rolled |
---|---|---|---|
Surface: | No.1,2D,2B,BA,No.4,8k,Tempered | Thickness: | 0.4mm~6mm |
Highlight: | 304 stainless steel sheet metal 2b finish,duplex steel plate 403,duplex steel plate 409 |
Grade 430 Stainless Steel Sheet
400 SERIES STAINLESS STEEL
Type 430 stainless steel combines good corrosion resistance with good formability and ductility. It is a ferritic, non-hardenable plain Chromium stainless steel with excellent finish quality. Grade 430 also has excellent resistance to nitric attack, which makes it well suited to use in chemical applications.
CHEMICAL COMPOSITION
Element | C | Mn | Cr | Ni | P | S | Si |
409 | 0.03% | 1.00% | 10.5~11.7% | 0.50% | 0.04% | 0.02% | 1.00% |
410 | 0.08~0.15% | 1.00% | 11.5~13.5% | 0.75% | 0.04% | 0.03% | 1.00% |
420 | 0.15% | 1.00% | 12.0~14.0% | - | 0.04% | 0.03% | 1.00% |
430 | 0.12% | 1.00% | 16.0~18.0% | 0.75% | 0.04% | 0.03% | 1.00% |
MECHANICAL PROPERTIES
Grade |
Tensile Strength (MPa) Min |
Yield Strength 0.2% proof (MPa) Min |
Elongation (%in 50mm) Min |
Brinell(HB) |
430 |
450
|
205 | 22 | 85 |
430 COMMON APPLICATIONS
The typical applications of grade 430 stainless steels are listed below:
