| Place of Origin: | Jiangsu, China |
|---|---|
| Brand Name: | Changjian |
| Certification: | ISO9001, CE |
| Minimum Order Quantity: | 1 ton |
| Delivery Time: | 7~10working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000 Ton/Tons per Month |
| Product Name: | Stainless Steel Sheet | Type: | Cold Rolled,Hot Rolled |
|---|---|---|---|
| Surface: | No.1,2D,2B,BA,No.4,8k,Tempered | Thickness: | 0.4mm~6mm |
| Highlight: | 308 Stainless Steel Sheet Plate,309 Stainless Steel Sheet Plate,diamond chequered plate ss 304 |
||
Grade 410 Stainless Steel Sheet
400 SERIES STAINLESS STEEL
Type 410 is hardenable, straight-chromium stainless steels which combine superior wear resistance of high carbon alloys with the excellent corrosion resistance of chromium stainless steels. Oil quenching these alloys from temperatures between 1800°F to 1950°F (982-1066°C) produces the highest strength and/or wear resistance as well as corrosion resistance. Type 410 alloy is used where strength, hardness, and/or wear resistance must be combined with corrosion resistance
CHEMICAL COMPOSITION
| Element | C | Mn | Cr | Ni | P | S | Si |
| 409 | 0.03% | 1.00% | 10.5~11.7% | 0.50% | 0.04% | 0.02% | 1.00% |
| 410 | 0.08~0.15% | 1.00% | 11.5~13.5% | 0.75% | 0.04% | 0.03% | 1.00% |
| 420 | 0.15% | 1.00% | 12.0~14.0% | - | 0.04% | 0.03% | 1.00% |
| 430 | 0.12% | 1.00% | 16.0~18.0% | 0.75% | 0.04% | 0.03% | 1.00% |
MECHANICAL PROPERTIES
| Grade |
Tensile Strength (MPa) Min |
Yield Strength 0.2% proof (MPa) Min |
Elongation (%in 50mm) Min |
Rockwell B(HRB) Max |
| 410 |
510
|
290 | 34 | 82-96 |
410 COMMON APPLICATIONS
The typical applications of grade 410 stainless steels are listed below:
