Product Name: | Carbon Steel Flat Bar | Thickness: | ≥3mm |
---|---|---|---|
Delivery Condition: | Annealing,Normalized,Quench+Temper | Surface: | Black Finish,Peeled,Rough Turned |
Highlight: | 1045 steel flat bar,1095 carbon steel flat bar,1045 steel flat bar |
Mild Steel Flat Bar is a versatile product commonly used in fabrication. With a flat surface and square edge, Sizing is represented as Width x Thickness, for example 40 x 25 = (45 mm Wide x 25mm Thick).
1008 steel round bar is comprised of low carbon steel, which allows for ease of formability. Because it is low carbon and produces lower mechanical properties, 1008 steel bar is typically used in less critical applications such as threaded rod and concrete stakes. 1008 cold drawn steel bar offers greater strength due to its increased mechanical properties.
Product can be purchased in individual lengths or as a bundle and we can also cut to length.
GRADE
AISI |
AISI 1008 AISI 1015 AISI 1017 AISI 1021 AISI 1025 AISI 1026 AISI 1035 AISI 1045 AISI 1050 AISI 1055 |
ASTM |
SAE 1006 SAE 1008 SAE 1010 SAE 1020 SAE 1030 SAE 1030 SAE 1035 SAE 1040 SAE 1045 |
JIS | SCM415 SCM420 SCM440 SS400 S45C S20C |
GB | Q195 Q215 Q235 |
SIZE
Size(mm) | Weight(kg/m) | Length(m) |
10 × 3 | 0.24 | ≥4 |
13 × 3 | 0.31 | ≥4 |
13 × 5 | 0.51 | ≥4 |
13 × 6 | 0.61 | ≥4 |
16 × 3 | 0.38 | ≥4 |
16 × 5 | 0.63 | ≥4 |
... | ... | ... |
EQUIVALENT GRADE OF 1008
EN | Germany DIN | IS | Japan JIS |
2A | C10 | C5 | SWRCH8A |
CHEMICAL COMPOSITION
Element | C | Mn | P | S |
1006 | 0.08% Max | 0.25~0.40% | 0.04%Max | 0.05%Max |
1008 | 0.10%Max | 0.30~0.50% | 0.04%Max | 0.05%Max |
1010 | 0.08~0.13% | 0.30~0.60% | 0.04%Max | 0.05%Max |
1020 | 0.18~0.23% | 0.30~0.60% | 0.04%Max | 0.05%Max |
1025 | 0.22~0.28% | 0.30~0.60% | 0.04%Max | 0.05%Max |
1045 | 0.43~0.50% | 0.60~0.90% | 0.04%Max | 0.05%Max |
HEAT TREATMENT
It can be heat treated at the following temperatures:
